ME460
MINI ELEPHANT
| Availability: | |
|---|---|
| Quantity: | |
It can be flexibly operated in narrow Spaces such as city streets,factory workshops,warehouses,etc
High-power engines are adopted,featuring high power,low fuel consumption and highefficiency
The hydraulic device of the lifting arm has along service life and the workingefficiency can becustomized
The dual hydraulic pumpsystemenhances mechanical reliability and safety
It can be equipped with various assistive devices and is compact and convenient
The characteristics of the ME460 remote-control multi-function loader
1. The ME460 is equipped with a Runtong R740 gasoline engine. With a displacement of 739 cc, maximum power of 16.8 kW at 3600 rpm, and 24 horsepower, it provides strong power output for efficient daily operation.
2. The machine adopts a single-cylinder, four-stroke, air-cooled, vertical engine structure, featuring stable performance, convenient maintenance, and reliable operation in different working conditions.
3. The overall dimensions are 2285 × 1100 × 1270 mm, and the overall weight is 890 kg. Its compact body allows the machine to work flexibly in narrow spaces such as urban streets, workshops, warehouses, and small job sites.
4. The ME460 has a rated load of 200 kg and a maximum load of 375 kg. With a bucket capacity of 0.15 m³, it is suitable for light material loading, transportation, site cleaning, and small engineering tasks.
5. The maximum unloading height reaches 1880 mm, making it convenient for loading materials into small trucks, containers, bins, and other receiving equipment.
6. The hydraulic pressure reaches 17 MPa. The lifting arm hydraulic system is designed for long service life and stable working efficiency, helping improve reliability and safety during operation.
7. The machine has a climbing ability of 30 degrees and a walking speed of 0-6 km/h, providing good mobility and adaptability on different job sites.
8. The ME460 can be equipped with various auxiliary devices according to customer needs. Optional configurations include wheeled type, triangular track, three pumps and three valves, four-wheel drive, and different engine options.
9. With its compact structure, flexible control, low fuel consumption, and high working efficiency, the ME460 is a practical choice for users who need a convenient multi-function machine for confined or complex work areas.
Engine model | Runtong R740 | Overall dimensions (mm) | 2285*1100*1270 |
Powertype | Single cylinder, four stroke, air cooled, vertical | overall weight(kg) | 890 |
Displacement(c) | 739 | Rated load(kg) | 200 |
Maximum power(kW/rpm) | 16.8/3600 | Maximum load(kg) | 375 |
Horsepower (HP) | 24 | Maximum unloadingheight(mm) | 1880 |
Fueltype | petrol | Hydraulic(MPa) | 17 |
Fuel consumption (g/kWh) | 370 | Climbing ability | 30° |
Fuelcapacity(L) | 25 | Walking speed(km/h) | 0-6 |
oil capacity(L) | 1.6 | Bucket capacity(m³) | 0.15 |
Engine optiona:lithum battery,Runtong R420,BriggsStratton 3864,Brigs8Stratton 25T2,Science Popularization 192(National I), Science Populaization 192(Europeanv) optional configurations:wheeled,triangular track,three pumps and three valves,four-wheel drive | |||
About our company
MINI ELEPHANT HEAVY INDUSTRY GROUP is located at No. 1668, Chongwen Avenue, Rencheng District, Jining City, Shandong Province, China. Established in 2021, the company currently has six factories and more than 300 employees, with a monthly production and sales capacity of over 2,000 units. Our main products include excavators, skid steer loaders, dump trucks, forklifts, rollers, and other construction machinery. With strong research and development capability, strict quality control, and reliable after-sales service, we are committed to providing high-quality machinery solutions to customers worldwide.
If you are interested in our ME460 remote-control multi-function loader, please feel free to contact us for more details, optional configurations, and quotation support. We look forward to cooperating with you and providing suitable equipment solutions for your projects.
