1200D
MINI ELEPHANT
| Availability: | |
|---|---|
| Quantity: | |
Parameter | Specification |
Operating Weight (kg) | 1220 |
Bucket Capacity (m³) | 0.12 |
Travel Speed Low / High (km/h) | 0-6 |
Gradeability (%) | 25 |
Maximum Lifting Force (kg) | 260 |
Maximum Working Height C (mm) | 2446 |
Maximum Dumping Height A (mm) | 2100 |
Dumping Reach G at Max Dumping Height (mm) | 400 |
Bucket Width E (mm) | 1016 |
Overall Length JK (mm) | 2400 |
Overall Width N (mm) | 1025 |
Upper Structure Width O (mm) | 960 |
Overall Height D (mm) | 1542 |
Working Radius M (mm) | 1500 |
Engine Brand | Yanmar |
Engine Model | 374 |
Maximum Horsepower (ps) | 15.23 |
Maximum Power (kW) | 11.2 |
Maximum Rotation Speed (rpm) | 2400 |
Displacement (cc) | 739 |
Number of Cylinders | 3 |
Cooling Method | Water Cooling |
Engine Oil Refill Volume (L) | 1.6 |
Larger Compact Loader
Loader 1200 Diesel Oil should be described as a stronger compact loader for buyers who need more operating weight, lifting ability and working height than the smaller loader models. This page should not copy Loader 290 or Loader 380 language; it needs to read like a higher-duty handling machine.
Specification Strength
The table lists 1220 kg operating weight, 0.12 m3 bucket capacity, 0-6 km/h travel speed, 25 percent gradeability, 260 kg maximum lifting force, 2446 mm maximum working height, 2100 mm dumping height and Yanmar engine information. These figures give the page a clear performance base.
Work Applications
Suitable scenes include farm material transfer, landscaping supply yards, small construction loading, snow or debris clearing, and loading into trailers or bins. The 2100 mm dumping height should be connected to real loading tasks, while the compact width helps explain where the machine can operate.
Buyer Guidance
Add confirmed attachment options, hydraulic specifications, tire or track configuration, packing size and spare parts support. A buyer comparing this page with 290/330/380 models should immediately see that Loader 1200 is for heavier daily handling and higher dumping requirements.
